Low Power > SUMMIT Series

Transmitters; Gapfillers ReTransmitters; Transposers From 1Wrms up to 150Wrms

Low Power SUMMIT Series
Key Facts
  • 1 W to 150W output power for DVB-T, DVB-T2, DVB-H, ISDB-TB,
  • Available as TV Transmitter, Re-transmitter, Transposer and On-channel Repeater
  • Broadband operation: Frequency range 470 MHz to 862 MHz
Overview
  • SUMMIT series is a complete range of TV Transmitters, Re-transmitters, Transposers and On-channel Repeaters for Digital TV and Mobile TV.
  • Its highly compact design allows allocating a complete 150Wrms UHF transmitter in a standard 19” rack in only 2U height
  • Its modular conception provides the flexibility to configure the equipment as Transmitter, Re-transmitter, Transposer or On-channel repeater (echo canceller is available for on-channel repeater configuration).
  • Redundant configurations, providing improved availability, are also available on SUMMIT series.
Key Features
Compactness
  • Slim exciter (1U) with local & remote control capabilities
  • Broadband ultra-compactamplifiers with integrated cooling system
Flexibilty
  • Output power range up to 150Wrms UHF
  • Available as Transmitter, Re-transmitter, Transposer and On-channel repeater
  • Several redundant configurations available to increase service availability
  • Modular conception allows customization through integration of options in order to meet every specific requirement
Low opex
  • Power consumption reduction thanks to very-high efficient broadband amplifiers
  • Highest availability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools (including SNMP, Web, GSM/GPRS,…)
  • Cost-effective redundancy options (including DD, 1+1 N+1 and N+M

Low Power > MODULAR Series

Transmitters; Gapfillers ReTransmitters; Transposers From 1Wrms up to 10Wrms

Low Power MODULAR Series
Key Facts
  • 1 W, 2W, 5W and 10W output power
  • Broadband operation: Frequency range 470 MHz to 862 MHz
  • Multi-transmitter system for transmitters, Transposers, Re-transmitters and On-channel Repeater
  • Cost-saving, compact solution for low-power Digital TV network expansion
  • Flexible system providing customized solutions
  • Designed for use in environments with limited infrastructure
Overview
  • MODULAR series features a highly compact multi-channel solution, supporting of all major Digital and Analogue TV standards.
  • Its modular conception allows the flexibility to configure the equipment in several ways, being able to operate as Transmitter, Transposer, Re-Transmitter or On-channel Repeater (with Mier’sinternationally patented echo canceller system).
  • MODULAR series has a main focus: cover the needs of low-power network expansion phases making use of extremely reliable and efficient technology. To comply with this need, the equipment has been designed with maximum roughness criteria to minimise maintenance, offering a complete set of options to reduce and ease network operation and maintenance.
  • MODULAR series is probably the most widely proven solution for Digital broadcast worldwide, with almost 10.000 equipment already supplied and in successful operation.
Key Features
Flexibilty
  • Highest flexibility level, which allows configuring any module combination (transmitters and repeaters, etc. in the same frame, mixing different output power levels), including optional modules like GPS receivers, remote control modules …
  • Direct and fast conversion from transmitter to repeater and vice versa
  • Several redundant configurations (1+1, N+1,..) available to increase service availability
Compactness
  • Low weight and compact solution installable in standard 19” rack
  • Up to 4 Multiplex in a single 4U sub-frame (+2U for cooling purposes).
Simple setup
  • Low weight and compact solution installable in standard 19” rack
  • No external cooling infrastructure is required
  • Fast&simpleset&go installation through extremely friendly GUI and automatic settings loading
Lowest opex
  • Power consumption reduction thanks to very-high efficient amplifiers
  • Highest availability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools: MODULARseries equipment provides an open control architecture to support integration in almost any Network Management System
  • Cost-effective redundancy options (including 1+1 and N+1). Redundant Power supply is also available as an option, providing improved system availability

Low Power > URBAN Series

Perfect solution for Mobile TV and Digital TV deployment

Low Power URBAN Series
Key Facts
  • 1Wrms output power
  • Broadband operation: Frequency range 470 MHz to 862 MHz
  • Available as transposer and on-channel repeater with optional  echo canceller for Mobile TV indoor coverage and outdoor coverage improvement
  • Automatic power control simplifies installation and provides continuity of service under any environment condition.
  • Cost-saving, compact solution for low-power Digital TV network expansion
  • Small, light and easy to install. Suitable solution for airports, hotels, malls, stadiums …
Overview
  • URBAN series features a highly compact solution, supporting all major Digital TV standards.
  • Its modular design allows the flexibility to configure the equipment as Transposer or On-channel repeater (with internationally patented echo canceller system).
  • URBAN series covers the needs of low-power network expansion phases making use of highly reliable and efficient technology, allowing an extremely  easy network operation and maintenance.

Medium Power > SUMMIT Series

Multi-standard Transmitters From 300Wrms and above

Medium Power SUMMIT Series
Key Facts
  • 300 W to 1.200W output power for DVB-T, DVB-T2, DVB-H, ISDB-TB
  • Broadband operation: Frequency range 470 MHz to 862 MHz
Overview
  • SUMMIT series is a complete range of TV Transmitters for Digital TV and Mobile TV.
  • Its highly compact design allows allocating a complete 1.200Wrms UHF transmitter in a standard 19” rack in only 9U height
  • Redundant configurations, providing improved availability, are also available on SUMMIT series.
Key Features
Compactness
  • Slim exciter (1U) with local & remote control capabilities
  • Broadband ultra-compactamplifiers with integrated cooling system
Flexibilty
  • Output power range from 300W up to 1.200Wrms UHF
  • Several redundant configurations available to increase service availability
  • Modular conception allows customization through integration of options in order to meet every specific requirement
Low opex
  • Power consumption reduction thanks to very-high efficient broadband amplifiers
  • Highest availability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools (including SNMP, Web, GSM/GPRS,…)
  • Cost-effective redundancy options (including DD, 1+1 N+1 and N+M)

Medium Power > MC2 Series

High Efficiency Transmitters From 200Wrms and above Minimum TCO

Medium Power MC2 Series
Key Facts
  • 200 W to 1.8 kW output power for DVB-T, DVB-T2, DVB-H, ISDB-TB
  • System efficiency above 35 %
  • The smallest footprint in the market
  • Simple startup, easy operation
  • High availability
Overview
  • The MC2 Series provides system efficiency above 35%, reducing dramatically energy costs, by means of an innovative amplification technique.
  • The improved efficiency drives to the lowest OPEX in the market, providing the minimum Total Cost of Ownership.
  • Compared to traditional amplifiers, the innovative very-high efficiency amplifiers included in MC2 Series provide a strong decrease in operating junction transistor temperature, which has a relevant impact on the MTBF of the system due to the lower thermal stress of the amplifier components.
  • The MC2Series also offers the possibility to incorporate redundant configurations on a simple and scalable way, for improved availability.
  • The Modular design of MC2 Series also provides a high serviceability, since the hot swappable units can be replaced while keeping transmission on air. Additionally, the internal design of the Power amplifier units provides an extremely easy access to internal Fans, Air Filters and Power supply modules, allowing on-site module exchange without requiring specific technical skills, special tools or test equipment.
Key Features
Maximum efficiency
  • Superior efficiency reducing dramatically energy costs
  • Innovative very high efficiency amplifier
Lowest opex
  • Highest availability, serviceability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools for simplified operation
  • Cost-effective redundancy options
Compactness
  • The most compact transmitters in its power class
  • Slim exciter (1U) with local & remote control capabilities
  • Ultra-compact and very high efficient amplifiers with integrated cooling system

High Power > SUMMIT Series

Multi-standard Transmitters Up to 5KWrms High availability

High Power SUMMIT Series
Key Facts
  • 1.2 kWrms to 5 kWrms output power for DVB-T, DVB-T2, DVB-H, ISDB-TB,
  • Broadband operation: Frequency range 470 MHz to 862 MHz
Overview
  • SUMMIT series is a complete range of TV Transmitters for Digital TV and Mobile TV.
  • Redundant configurations, providing improved availability, are also available on SUMMIT series.
Key Features
Compactness
  • Slim exciter (1U) with local & remote control capabilities
  • Broadband ultra-compactamplifiers with integrated cooling system
Flexibilty
  • Output power range up to 5.000Wrms UHF
  • Available as Transmitter, Re-transmitter, Transposer and On-channel repeater
  • Several redundant configurations available to increase service availability
  • Modular conception allows customization through integration of options in order to meet every specific requirement
Low opex
  • Power consumption reduction thanks to very-high efficient broadband amplifiers
  • Highest availability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools (including SNMP, Web, GSM/GPRS,…)
  • Cost-effective redundancy options (including DD, 1+1 N+1 and N+M)

High Power > MC2 Series

The best efficiency in the market Up to 5KWrms Minimum TCO

High Power MC2 Series
Key Facts
  • 1.2 KWrms to 5 kWrms output power for DVB-T, DVB-T2, DVB-H, ISDB-TB
  • System efficiency above 35 %
  • The smallest footprint in the market
  • Simple startup, easy operation
  • High availability
Overview
  • The MC2 Series provides system efficiency above 35%, reducing dramatically energy costs, by means of an innovative amplification technique.
  • The improved efficiency drives to the lowest OPEX in the market, providing the minimum Total Cost of Ownership.
  • Compared to traditional amplifiers, the innovative very-high efficiency amplifiers included in MC2 Series provide a strong decrease in operating junction transistor temperature, which has a relevant impact on the MTBF of the system due to the lower thermal stress of the amplifier components.
  • The MC2Series also offers the possibility to incorporate redundant configurations on a simple and scalable way, for improved availability.
  • The Modular design of MC2 Series also provides a high serviceability, since the hot swappable units can be replaced while keeping transmission on air. Additionally, the internal design of the Power amplifier units provides an extremely easy access to internal Fans, Air Filters and Power supply modules, allowing on-site module exchange without requiring specific technical skills, special tools or test equipment.
Key Features
Maximum efficiency
  • Superior efficiency reducing dramatically energy costs
  • Innovative very high efficiency amplifier
Lowest opex
  • Highest availability, serviceability & reliability allows lower maintenance costs
  • Flexible remote control & monitoring tools for simplified operation
  • Cost-effective redundancy options
Compactness
  • The most compact transmitters in its power class
  • Slim exciter (1U) with local & remote control capabilities
  • Ultra-compact and very high efficient amplifiers with integrated cooling system
